EQUIPMENTS in ESML
ANALYSIS
Weve
Raman
Raman spectrometer for structural and bonding analysis
Thermo Scientific™
iXR raman
Raman system for rapid, non-destructive surface identification.
Nexis
GC-2030 Gas Chromatograph
Gas chromatography system for separating and analyzing volatile components
SNM
Sheet Resistance
Measures sheet resistance of coated films or electrodes
CORE INFRASTRUCTURE
SINOPRO
Glove box 3 port
Mainly used for pouch-cell work and storage of active materials or moisture-sensitive components
KIYON
Glove box 3 port
Mainly used for coin-cell assembly under an inert atmosphere.
Electrochemical Testing & Evaluation
Bio-Logic
SP-200
Transportable potentiostat/galvanostat for CV, EIS, and other electrochemical tests.
Bio-Logic
VSP-3e, 4-channel
Multi-channel potentiostat/galvanostat for parallel electrochemical measurements.
NEWARE
Battery Testing System
CT-400
Battery cycler for charge-discharge, rate, and cycle-life testing
NEWARE
Environmental Test Chamber WHW-200L
Constant-temperature chamber for stable battery testing environments
DASOL
Battery Testing Chamber
Environmental chamber for battery cycling under controlled temperature conditions
JEIOtech
Heating & Cooling Chamber
Temperature-control chamber for conditioning samples or tests
ASSB
SINOPRO
Glove box 2 port
Compact glove box for air-sensitive materials and ASSB-related. handling
HANtech
Hydraulic Lab Press HLP-5
Hydraulic press for pelletizing or pressing solid-state battery components
NEOSCIENCE
SSB CeLL Jig TLP1109-ADS
Test jig for assembling or evaluating solid-state battery cells
Cell Assembly
SINOPRO
Button battery manual Crimping machine SP-SF120
Coin-cell-dedicated manual crimping machine
_edited_edited.png)
Rohtec
Coin cell crimping M/C (M01)
Coin-cell sealing machine for consistent crimping
SINOPRO
Small hydraulic die cutting machine SP-XMQ100
Hydraulic die cutter for pouch-cell components or electrodes
SINOPRO
Vacuum pre-sealing machine SP-YF200
Pre-seals the pouch before final processing
SINOPRO
Vacuum filling and standing all-in-one machine SP-ZY65
Fills electrolyte under vacuum and allows standing
SINOPRO
Secondary vacuum final sealing machine SP-BFZ200
Final vacuum sealing for completed pouch cells.
SINOPRO
Lithium battery Thermal sealing machine SP-SFZ200
Heat-seals pouch materials during cell assembly
SINOPRO
Pneumatic pole piece die cutting machine SP-QMQ85
Cuts electrode sheets or pole pieces to the required shape.
Sample & Slurry Preparation
THINKY
Planetary Centrifugal Mixer AR-100
Blade-free mixer for homogeneous slurry mixing and deaeration
SINOPRO
Automatic film coating machine SP-TM300
Produces uniform electrode coatings on current collectors
METTLER TOLEDO
Balance EL204
Analytical balance for accurate mass measurements
%20SP-DG200L_edited_edited.png)
SINOPRO
Electric vertical roller press SP-DG200L
Densifies electrode sheets to improve thickness uniformity and contact.
VILBER
UV Irradiators
UV irradiation system for light-based treatment or curing
Young Jin Corporation
Watts Ultrasonic Processor VCX-750
Probe sonicator for dispersion, exfoliation, and particle breakup
HwashinTech
Powersonic 510
Ultrasonic bath for cleaning or gentle dispersion
LK lab
High Speed Centrifuge, VELOSPIN L17R
High-speed centrifuge for separation and washing of suspensions
Thermo Scientific™
pH/Conductivity Benchtop Multiparameter Meter Kit Orion STARA215
Benchtop meter for pH and conductivity measurement
Thermo Processing & Drying
Daihan
Gravity-air Incubator
Mild-temperature chamber for drying or controlled storage
JEIOtech
Vacuum Oven OV3-30
Vacuum drying oven for moisture-sensitive materials
JEIOtech
Vacuum Oven OV4-30
Additional vacuum oven for drying and solvent removal
JEIOtech
Forced Convection Oven
OF-02
Forced-air oven for uniform heating and drying
HANtech
High-Temperature Tube Furnace
Tube furnace for calcination and high-temperature heat treatment
HANtech
High-Temperature Tube Furnace
Additional tube furnace for high-temperature processing
Safety
JEIOtech
Flammable Storage Cabinet SC2-60F-0806D1-C
Safety cabinet for flammable chemicals
JEIOtech
Ductless Fume Hood Cabinet ZEO-SD142F
Local containment cabinet for routine reagent handling
SIMULATION
COMSOL
FEM
Multiphysics simulation for transport, heat, and electrochemical behavior.
Materials design
DFT / MD Simulation — VASP / MedeA
First-principles modeling of structures and electronic properties
ALTAIR
DEM-EDEM
Particle-based modeling of powder flow and particulate behavior
CPU 240 core
Work Station
High-performance computing resource for large simulations and data processing
